.16x16 digital matrix .Programming and control by integrated web server and standard web navigator (no additional software required). .Control from the front panel and user remote control by:
• eMCONTROL1 wall panels (up to 8)
• eMPAGE warning consoles (up to 2)
• pilot eMIMO application, compatible with Android and iOS: control graphic panels set to user requirements
• TP-NET protocol for control and integrating with third party systems .Control available, by zone (output): selection of audio source (input), volumen adjustment and MUTE, 3 band tone adjustment .Input distribution, by type:
• 4 x ST LINE
• 4 x MICRO / MONO LINE with priority function that can be activated
• 8 x MONO LINEA available in REMOTE ports, from wall panels and eMCONTROL1
-.Priority function with two levels: inputs 5 to 8 MIC/LINE can attenuate (or completely mute) the sound content present (program audio) in specific target zones (emergency messages, warnings, etc.), in Talkover or Pager mode
-.MUTE port can be activated by closing the external dry contact, affecting programmed outputs to this effect
